Create colorful world
Neitabond Design series have smooth surface, color diversity, strong and beautiful, strong impact resistance, seismic resistance, easy processing, quick construction, and it has characteristics of adapting various kinds of harsh environment. In line with the world trend, it is the first selection of decorative panel materials. After the products listed, they are respected and loved by the architects, contractors and the majority of users, projects performance is all over the world. Widely used for public places indoor and outdoor decoration, commercial malls, exhibition advertising, auto 4S shop decoration and display.
Neitabond Designs vividly imitate the subtle texture of different pictures and easy to clean surface, can be directly wiped with water once dust contamination, with recyclable, anticorrosion features, it is belong to green and environmentally-friendly building materials, has long service life and wear resistance.
Soft white or bright red? Solid colours are always a good choice when a uniform appearance without special effects is required.
Economy
High resistance to peeling
Superior weather resistance
Light weight and easy to process
Excellent fire resistance properties
Coating evenness
Diversified colors
Easy for maintenance
Impact resistance
| Surface coating | Polyester wooden coating |
| Aluminum alloy | AA1100 series |
| Aluminum skin | 0.08mm,0.10mm,0.12mm,0.15mm,0.21mm, |
| 0.25mm,0.30mm,0.35mm,0.40mm,0.45mm,0.50mm | |
| Panel thickness | 3mm, 4mm,5mm,6mm |
| Panel width | 1220mm,1250mm,1500mm |
| Panel length | 2440mm,3050mm,5000mm |
| Backing coating | Primer coating |
| Glossy | 40%-70% |
| Description | Test standard | Polyester |
| Thickness of coating | Polyester paint ≥16um | 16um to 18um |
Coating flexibility (T-bend) | Polyester paint≥3T | 3T |
| Color different | △E ≤ 2.0(follow color sample) | ΔE ≤ 2.0 |
| Pencil hardness | ≥HB | ≥2H |
| Chemical resistance | 2%HCI or 2% NaOH test in 24 hours -No change | No change |
| Coating adhesion | ≥ 1grade for 10810m m2gridding test | 1grade |
| Resist solvent | 100times with Dimethylebnzene without change | No change |
| Boiling water resistance | 2 hours without change | No change |
Peeling strength/ stripping strength | Average ≥5N/mm of 180oc peel off for panel with 0.21mm alu.skin | 5N/mm |
| Impact test for paint | 20KG.cm impact-paint no split for panel | No split |
| Abrasion resistance (L/Mil) | NIL | NIL |
| Temperature resistance | -40℃ to +80℃ temperature without change of color difference and paint peel off,peeling strength average drop rate≤10% | Change of glossy only, no paint |
| Peel off | ||
| Coefficient of linear Thermal Expansion | 100℃ temperature difference | 2.4mm/n |
| Detergent resistance (3%) | ASTM D2248 | No change |
Humidity Resistance (3000hrs,100%RH,100°F) | ASTM D2247 | No change |
Salt spray resistance (3000hrs,5% salt) | ASTM B117 | No change |
| Resistance to Staining | 600h radiate in 800W/M2 in humidity condition,glossiness deviation less grade 2, color difference ≤4.0 | No change |
The company possesses production lines for aluminum-plastic panels whose annual output is 520 million square meters.
